- Kirjeldus
Kirjeldus
Output voltage at 1 kHz, 5cm/sec: 1.5 mV
Frequency response 20 Hz – 20 kHz: 3 / -1 dB
Tracking ability at 315Hz at recommended tracking force: 60 µm
Compliance, dynamic, lateral: 7 µm/mN
Stylus type: Spherical
Stylus tip radius: R 65 µm
Tracking force range: 4.0-5.0 g (40-50 mN)
Tracking force, recommended: 4.5 g (45 mN)
Tracking angle: 20°
Internal impedance, DC resistance: 6 ohm
Recommended load impedance: 100 ohm
Coil wire material: High Purity Copper (OFC)
Cartridge body material: Ground wood and resin composite
Cartridge colour: Black matte
Cartridge weight: 35 g
