NAIM SUPERNAIT 2

Kirjeldus

– 80W per channel power output
– Six individually decoupled and hand-wired inputs with support for both DIN and RCA connections
– Built in Naim Audio DR (Discrete Regulator) power supply for preamplifier section
– 1/4” (6.35mm) headphone output and high quality class-A headphone amplifier
– Ceramic heat sink isolation for improved sound quality on power and preamp sections
– Dedicated subwoofer output
– Powered input for use with StageLine or SuperLine phono stage

Power
Mains Supply: 100V, 115V, 230V; 50 or 60Hz
Power Consumption (quiescent): 10VA

Audio Outputs
Audio Outputs: Speakers, record, preamp and variable sub
Other Outputs: Headphone, 1/4″ jack
Line Outputs Variable (level): 775mV, <50Ω
Line Outputs Fixed (level): 130mV, 600Ω
Power Outputs: Naim phono amplifier

Physical
Shipping Weight: 15.3 kg
Shipping Dimensions: 240 x 590 x 500 mm
Weight: 12.8 kg
Dimensions (HxWxD): 87 x 432 x 314 mm

User Control
Front Panel: Volume Control, Balance Control, seven button matrix

Remote Control: Infra Red (RC5)

Connectivity
Updates: 1 x USB Type Mini-B
Remote Input: 1 x 3.5mm jack on rear (RC5 modulated/unmodulated)

Speaker Outputs
Power Output: 80W/channel, 8Ω

Finish
Case: Black powder coated
Front: Brushed and black anodised

Supplied with
Supplied with: NARCOM-4 Remote Control, Power-Line Lite mains cable (UK denominations only)

Audio Inputs
Input Impedance: 47kΩ
Analogue Input: 4 x DIN/RCA pair, 1 x RCA pair, 1 x DIN (for Naim phono amplifier)
Input Sensitivity: 130mV
