NAIM NAC 282

Kirjeldus

– Support for both DIN and RCA inputs to facilitate connection into a wider range of systems
– Silent microprocessor control that sleeps during listening
– Precision rotary potentiometers with precious metal wipers
– AV bypass mode for simple connection to an existing AV system
– Powered input for use with StageLine or SuperLine phono stages
– Performance upgradable with FlatCap XS, HiCap or SuperCap power supply; can also be powered from the preamp inputs of the NAP 155 XS or NAP 200 power amplifier

Audio Outputs
Audio Outputs: 2 x variable (DIN), 3 x fixed (DIN)
Other Outputs: <50Ω
Line Outputs Variable (level): 775mV
Line Outputs Fixed (level): 75mV, 600Ω
Load Impedance: 10kΩ (min.)
Power Outputs: Naim phono amplifier

Audio Inputs
Other Inputs: AV input configurable for unity gain
Input Impedance: 47kΩ
Analogue Input: 4 x DIN, 2 x DIN, RCA
Input Sensitivity: 75mV

Connectivity
RS232: Optional (DE9 female)
Remote Input: RCA on rear (RC5)

Upgrades
Power Supply: 2 x Hi-Cap/SuperCap
Other: NAPSC

User Control
Front Panel: Volume control, balance control, sixteen button matrix
Handheld: NARCOM-4 Remote Control
Remote Control: Infra Red (RC5)

Finish
Case: Black powder coated
Front: Brushed and black anodised

Supplied with
Supplied with: NARCOM-4 Remote Control

Power
Power Supply Options: NAP 155 XS, NAP 200, FlatCap XS, HiCap, SuperCap
Supply Voltage: 18V, 24V

Physical
Weight: 7.0 kg
Dimensions (HxWxD): 87 x 432 x 314 mm
