JL Audio M7-12IB-C-GwGw-4

Kirjeldus

Omadused:
Mõõt: 12″ / 30cm
Võimsus: 600RMS
Takistus: 4 Ω
Paigaldusava: 306mm
Paigaldussügavus: 202mm
Soovitatav suletud kast: –
Soovitatav porditud kast: 56.6 – 70.8L

Free Air Resonance (Fs) 35.34 Hz
Electrical “Q” (Qes) 0.856
Mechanical “Q” (Qms) 10.389
Total Speaker “Q” (Qts) 0.791
Equivalent Compliance (Vas) 1.99 cu ft / 56.35 L
One-Way Linear Excursion (Xmax)* 0.73 in / 18.5 mm
Reference Efficiency (no) 0.28%
Efficiency (1 W / 1 m)** 86.7 dB SPL
Effective Piston Area (Sd) 80.54 sq in / 0.052 sq m
DC Resistance (Re) 3.543 Ω
